| Nombor Bahagian | NT116WHM-A20 |
| Jenama | BOE |
| Saiz | 11.6 |
| Permohonan | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 8S4P |
| Antara muka | |
| jenama panel | BOE |
| saiz panel | 11.6" |
| resolusi | 1366(RGB)×768, WXGA, 135PPI |
| kawasan paparan | 256.125(W)×144(H) mm |
| saiz garis besar | 278(W)×171.55(H) ×4.9(D) mm |
| kecerahan | 200 cd/m² (Typ.) |
| sudut pandangan | 45/45/20/40 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K 48% NTSC |
| kekerapan | 60Hz |
| gaya bentuk | Flat (PCBA Flat, T3.4~4.0mm) |
| model panel | NT116WHM-A20 (BOE063F) |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating (7H) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 12 (Typ.)(Tr+Td) |
| jenis lampu | 8S4P WLED , 15K hours , With LED Driver |
| skrin sentuh | PCAP, Optical Bonding |
| permohonan | Laptop |
