| Nombor Bahagian | NL6448BC26-17 |
| Jenama | NLT |
| Saiz | 8.4 |
| Permohonan | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 262K/16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | NEC |
| model panel | NL6448BC26-17 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 8.4 inch |
| resolusi | 640(RGB)×480 , VGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 170.88×128.16 mm |
| permukaan | |
| kecerahan | |
| nisbah kontras | |
| warna paparan | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| masa tindak balas | |
| sudut pandangan | |
| kekerapan | 60Hz |
| jenis lampu | 2 pcsCCFL |
| antara muka isyarat | LVDS (1 ch, 6-bit) |
| permohonan | IA |
