| Nombor Bahagian | NL6448AC33-A1D |
| Jenama | NLT |
| Saiz | 10.4 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | |
| pengilang | NLT |
| nama model | NL6448AC33-A1D |
| saiz skrin | 10.4 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 640(RGB)×480 (VGA) 76PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 211.2 × 158.4 (H×V) |
| garis besar (mm) | 227.3 × 177.5 × 9.8 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare |
| kecerahan | 370 cd/m² (Typ.) |
| nisbah kontras | 900 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| tindak balas | 18 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K |
| lampu latar | WLED , 100K hours , With LED Driver |
| jisim | 380g (Max.) |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
