| Nombor Bahagian | NL6448AC33-A0D |
| Jenama | NLT |
| Saiz | 10.4 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | CMOS |
| jenama panel | NLT |
| saiz panel | 10.4" |
| resolusi | 640(RGB)×480, VGA, 76PPI |
| kawasan paparan | 211.2(W)×158.4(H) mm |
| saiz garis besar | 246.5(W)×179.4(H) ×10(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| pandangan terbaik pada | - |
| warna paparan | 262K 40% NTSC |
| kekerapan | 60Hz |
| berat panel | 390/435g (Typ./Max.) |
| antara muka isyarat | CMOS (1 ch, 6-bit) , 31 pins Connector |
| voltan masukan | 3.3/5.0V (Typ.) |
| persekitaran | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| model panel | NL6448AC33-A0D |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Antiglare, Hard coating (3H) |
| nisbah kontras | 900:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 3/15 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 100K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-18A | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
