| Nombor Bahagian | NE173FHM-NZ1 |
| Jenama | BOE |
| Saiz | 17.3 |
| Permohonan | Laptop Gaming |
| Resolusi | 1920×1080 |
| Komposisi | Oxide TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 10S6P |
| Antara muka | eDP |
| jenama panel | BOE |
| model panel | NE173FHM-NZ1 (BOE0884) |
| saiz panel | 17.3" |
| jenis panel | Oxide TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 127PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 381.888(W)×214.812(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 389.89(W)×238.31(H) ×3.5(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | ADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 4 (Typ.)(G to G) |
| warna paparan | 16.7M 100% sRGB |
| jenis lampu | 10S6P WLED , 15K hours , With LED Driver |
| kekerapan | 240Hz |
| skrin sentuh | Without |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| permohonan | Laptop Gaming |
| antara muka isyarat | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
