| Nombor Bahagian | NE160QDM-NY2 |
| Jenama | BOE |
| Saiz | 16.0 |
| Permohonan | Laptop Gaming |
| Resolusi | 2560×1600 |
| Komposisi | LCM, Oxide TFT-LCD |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 1.07B |
| Lampu latar | 10S6P |
| Antara muka | |
| pengilang | BOE |
| nama model | NE160QDM-NY2 (BOE0A20) |
| saiz skrin | 16.0 inch |
| jenis skrin | LCM, Oxide TFT-LCD |
| nombor piksel | 2560(RGB)×1600 (WQXGA) 188PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 344.678 × 215.424 (H×V) |
| garis besar (mm) | 349.68 × 231.42 × 3 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 1200 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 9 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 1.07B 100% sRGB |
| lampu latar | 10S6P WLED , 15K hours , With LED Driver |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| digunakan untuk | Laptop Gaming |
| kadar segar semula | 120Hz |
| skrin sentuh | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
