| Nombor Bahagian | MV238QHB-N10 |
| Jenama | BOE |
| Saiz | 23.8 |
| Permohonan | Desktop Monitor |
| Resolusi | 2560×1440 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | MV238QHB-N10 |
| saiz panel | 23.8" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 2560(RGB)×1440, Quad-HD, 123PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 526.848(W)×296.352(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 534.84(W)×308.16(H) ×1.32(D) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | ADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 14 (Typ.)(G to G) |
| kedalaman kaca | 0.50+0.50 mm |
| ketransmisian | - |
| warna paparan | 16.7M 100% sRGB |
| jenis lampu | No B/L |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| ic pemandu | COF Built-in 8 source chips |
| berat panel | TBD |
| permohonan | Desktop Monitor |
| antara muka isyarat | LVDS (4 ch, 8-bit) , 70 pins Connector |
| voltan masukan | 5.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
