Innolux MT185GW01 V.4 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


MT185GW01 V.4

MT185GW01 V.4
MT185GW01 V.4 thumb
Jenama
Innolux
Saiz
18.5
Permohonan
DMPC
Resolusi
1366×768
Komposisi
LCM
Kecerahan
250
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
30
Spesifikasi

Nombor Bahagian MT185GW01 V.4
JenamaInnolux
Saiz18.5
PermohonanDMPC
Resolusi1366×768
KomposisiLCM
Kecerahan250
CR1000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelCHIMEI INNOLUX
model panelMT185GW01 V.4
jenis panel a-Si TFT-LCD , LCM
saiz panel18.5 inch
resolusi1366(RGB)×768 , WXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif409.8×230.4 mm
garis besar430.37×254.6×10.25 mm
permukaanAntiglare (Haze 25%), Hard coating (3H)
kecerahan250 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M (6-bit + Hi-FRC), CIE193170%
masa tindak balas1.5/3.5 (Typ.)(Tr/Td)
sudut pandangan85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu14S6PWLEDWithout Driver
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
Model Keluarga
CLAA185WA02 CPT 18.5 1366×768
CLAA185WA03 CPT 18.5 1366×768
G185XW01 V1 AUO 18.5 1366×768
LM185WH1-TLC5 LG Display 18.5 1366×768
M185BGE-L22 Innolux 18.5 1366×768
M185BGE-P02 Innolux 18.5 1366×768
M185XTN01.2 AUO 18.5 1366×768
MT185GW01 V.0 Innolux 18.5 1366×768
MT185GW01 V.4 Innolux 18.5 1366×768
MT185WHM-N20 BOE 18.5 1366×768
