| Nombor Bahagian | MCG156FDLAAQNN-AN20 |
| Jenama | Kyocera |
| Saiz | 15.6 |
| Permohonan | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | LTPS TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | Kyocera |
| saiz panel | 15.6" |
| resolusi | 1920(RGB)×1080, FHD, 141PPI |
| kawasan paparan | 344.16(W)×193.59(H) mm |
| saiz garis besar | 363.8(W)×215.9(H) ×9.8(D) mm |
| kecerahan | 450 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.2M 73% NTSC |
| kekerapan | 60Hz |
| berat badan | 1.05/1.09Kgs (Typ./Max.) |
| model panel | MCG156FDLAAQNN-AN20 |
| jenis panel | LTPS TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 347.06(W)×196.49(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | AWV, Normally Black, Transmissive |
| masa tindak balas | 13/12 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 50K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
