| Nombor Bahagian | M240UW01 V3 |
| Jenama | AUO |
| Saiz | 24.0 |
| Permohonan | DMPC |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | M240UW01 V3 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 24.0 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | AMVA, Normally Black, Transmissive |
| kawasan aktif | 518.4×324 mm |
| garis besar | 546.4×352×36.3 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 10/6 (Typ.)(Tr/Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 6 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (2 ch, 8-bit), 30 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | DMPC |
| LM240WU5-SLA1 | LG Display | 24.0 | 1920×1200 |
| LM240WU8-SLD1 | LG Display | 24.0 | 1920×1200 |
| LTM240CT03 | Samsung | 24.0 | 1920×1200 |
| M240UP01 V0 | AUO | 24.0 | 1920×1200 |
| M240UW01 V0 | AUO | 24.0 | 1920×1200 |
| M240UW01 V2 | AUO | 24.0 | 1920×1200 |
| M240UW01 V3 | AUO | 24.0 | 1920×1200 |
| M240UW04 V0 | AUO | 24.0 | 1920×1200 |
| M240UW04 V1 | AUO | 24.0 | 1920×1200 |
| T240XW01 V1 | AUO | 24.0 | 1366×768 |
| FLC48SXC8V-11AA | Fujitsu | 19.0 | 1280×1024 |
| LM170E01-TLA1 | LG Display | 17.0 | 1280×1024 |
| LM190E08-TLJ8 | LG Display | 19.0 | 1280×1024 |
| LM270WQ1-SDB3 | LG Display | 27.0 | 2560×1440 |
| LTM150XH-L01 | Samsung | 15.0 | 1024×768 |
| LTM200KT03 | Samsung | 20.0 | 1600×900 |
| LTM200KT10 | Samsung | 20.0 | 1600×900 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M270DTN01.3 | AUO | 27.0 | 2560×1440 |
| P236MWF1 R2 | IVO | 23.6 | 1920×1080 |
