| Nombor Bahagian | M238DAN01.1Q0 |
| Jenama | AUO |
| Saiz | 23.8 |
| Permohonan | Desktop Monitor |
| Resolusi | 2560×1440 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 20S4P |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | M238DAN01.1Q0 |
| saiz panel | 23.8" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 2560(RGB)×1440, Quad-HD, 123PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 526.85(W)×296.35(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 534.74(W)×313.26(H) ×12.3(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | AHVA, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 14 (Typ.)(G to G) |
| warna paparan | 16.7M 100% sRGB |
| jenis lampu | 20S4P WLED , 30K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 2.20Kgs (Typ.) |
| permohonan | Desktop Monitor |
| antara muka isyarat | LVDS (4 ch, 8-bit) , 92 pins Connector |
| voltan masukan | 5.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
