| Nombor Bahagian | M104GNX2 R1 |
| Jenama | IVO |
| Saiz | 10.4 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | IVO |
| model panel | M104GNX2 R1 |
| saiz panel | 10.4" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×768, XGA, 123PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 211.2(W)×158.4(H) mm |
| pembukaan bezel | - |
| kecerahan | - |
| nisbah kontras | 900:1 (Typ.) (TM) |
| sudut pandangan | 70/70/50/60 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | - |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| warna paparan | 262K/16.7M 50% NTSC |
| jenis lampu | WLED |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| AA104VB04 | Mitsubishi | 10.4 | 640×480 |
| BA104S01-100 | BOE | 10.4 | 800×600 |
| G104V1-T03 | Innolux | 10.4 | 640×480 |
| G104X1-L02 | Innolux | 10.4 | 1024×768 |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| G6481L-FF | CITIZEN | 10.4 | 640×480 |
| LQ104V1DC41 | SHARP | 10.4 | 640×480 |
| LTM10C209H | TOSHIBA | 10.4 | 640×480 |
| M104GNX1 R1 | IVO | 10.4 | 1024×768 |
| TX26D203VM2BAA | KOE | 10.4 | 1024×768 |
