| Nombor Bahagian | M102AWF2 R1 |
| Jenama | IVO |
| Saiz | 10.3 |
| Permohonan | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | IVO |
| model | M102AWF2 R1 |
| saiz pepenjuru | 10.3 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×720 200PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 243.65(H)×91.37(V) mm |
| garis besar malap. | 262.04(H)×110.3(V) ×12.2(D) mm |
| kawasan bezel | 245.65(H)×93.66(V) mm |
| rawatan | Hard coating (3H) |
| kecerahan | 800 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | IPS, Normally Black, Transmissive |
| warna sokongan | 16.7M 72% NTSC |
| sumber cahaya | WLED [8S3P] , 10K hours , W/O Driver |
| berat badan | 380g (Max.) |
| direka untuk | Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (2 ch, 8-bit) , 50 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
