| Nombor Bahagian | LTN160HT02-001 |
| Jenama | Samsung |
| Saiz | 16.0 |
| Permohonan | NBPC |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | RGB LED |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTN160HT02-001 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 16.0 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 353.28×198.72 mm |
| garis besar | 365×217 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Antiglare (Haze 40%), Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), Adobe100% |
| masa tindak balas | 8 (Typ.)(Tr+Td) |
| sudut pandangan | 75/75/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | RGB LEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (2 ch, 6-bit), 50 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
