Samsung LTN133AT23-001 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LTN133AT23-001

LTN133AT23-001
LTN133AT23-001
LTN133AT23-001 thumb LTN133AT23-001 thumb
Jenama
Samsung
Saiz
13.3
Permohonan
NBPC
Resolusi
1366×768
Komposisi
LCM
Kecerahan
300
CR
220:1
Warna
262K
Lampu latar
WLED
Antara muka
LVDS
In Stock
18081
Spesifikasi

Nombor Bahagian LTN133AT23-001
JenamaSamsung
Saiz13.3
PermohonanNBPC
Resolusi1366×768
KomposisiLCM
Kecerahan300
CR220:1
Warna262K
Lampu latarWLED
Antara mukaLVDS
jenama panelSAMSUNG
model panelLTN133AT23-001
jenis panel a-Si TFT-LCD , LCM
saiz panel13.3 inch
resolusi1366(RGB)×768 , WXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif293.42×164.97 mm
permukaanAntiglare (Haze 25%)
kecerahan300 cd/m² (Min.)
nisbah kontras220:1 (Typ.)
warna paparan262K (6-bit), CIE193145%
masa tindak balas16 (Typ.)(Tr+Td)
sudut pandangan45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu8S4PWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (1 ch, 6-bit), 40 pins
voltan masukan3.3V (Typ.)
permohonanNBPC
Model Keluarga
LTN133AT07-G01 Samsung 13.3 1280×800
LTN133AT09-W01 Samsung 13.3 1280×800
LTN133AT13-001 Samsung 13.3 1280×800
LTN133AT14-001 Samsung 13.3 1280×800
LTN133AT16-L01 Samsung 13.3 1280×800
LTN133AT17-W01 Samsung 13.3 1366×768
LTN133AT23-803 Samsung 13.3 1366×768
LTN133AT23-C01 Samsung 13.3 1366×768
LTN133AT25-T01 Samsung 13.3 1366×768
LTN133AT27-102 Samsung 13.3 1366×768
