| Nombor Bahagian | LTM240CL01 |
| Jenama | Samsung |
| Saiz | 24.0 |
| Permohonan | DMPC |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTM240CL01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 24.0 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | PLS, Normally Black, Transmissive |
| kawasan aktif | 518.4×324 mm |
| garis besar | 546.4×352×15 mm |
| permukaan | Antiglare (Haze 47%), Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Hi-FRC), CIE193172% |
| masa tindak balas | 12 (Typ.)(Tr+Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 14S4PWLEDWithout Driver |
| antara muka isyarat | LVDS (2 ch, 8-bit), 30 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | DMPC |
