| Nombor Bahagian | LTM12C505D |
| Jenama | TOSHIBA |
| Saiz | 12.1 |
| Permohonan | NBPC |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 165 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | Toshiba Matsushita |
| model panel | LTM12C505D |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 12.1 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 245.76×184.32 mm |
| garis besar | 261×199×5.3 mm |
| permukaan | |
| kecerahan | 165 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 50/50 (Max.)(Tr/Td) |
| sudut pandangan | |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLEmbedded (Inverter) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 20 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
| LTM121SI-T01 | Samsung | 12.1 | 800×600 |
| LTM12C268F | TOSHIBA | 12.1 | 800×600 |
| LTM12C275A | TOSHIBA | 12.1 | 800×600 |
| LTM12C278F | TOSHIBA | 12.1 | 800×600 |
| LTM12C283 | TOSHIBA | 12.1 | 800×600 |
| LTM12C285 | TOSHIBA | 12.1 | 800×600 |
| LTM12C289 | TOSHIBA | 12.1 | 800×600 |
| LTM12C318S | TOSHIBA | 12.1 | 1024×768 |
| LTM12C505D | TOSHIBA | 12.1 | 1024×768 |
| LTM12C505T | TOSHIBA | 12.1 | 1024×768 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| B140XTN02.4 | AUO | 14.0 | 1366×768 |
| B154PW02 V3 | AUO | 15.4 | 1440×900 |
| B156XTN03.1 | AUO | 15.6 | 1366×768 |
| HB140WX1-500 | BOE | 14.0 | 1366×768 |
| LP141WX1-TL01 | LG Display | 14.1 | 1280×800 |
| LP156WH2-TLG1 | LG Display | 15.6 | 1366×768 |
| LTD111EWAX | TOSHIBA | 11.1 | 1366×768 |
| LTD131EQ2X | TOSHIBA | 13.1 | 1600×900 |
| LTD133KX2S | TOSHIBA | 13.3 | 1280×800 |
