| Nombor Bahagian | LTI820HT-L01 |
| Jenama | Samsung |
| Saiz | 82 |
| Permohonan | PID |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 600 |
| CR | 2000:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTI820HT-L01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 82 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | S-PVA, Normally Black, Transmissive |
| kawasan aktif | 1805.76×1015.74 mm |
| garis besar | 1878.6×1083.6 mm |
| permukaan | Antiglare (Haze 40%), Hard coating (3H) |
| kecerahan | 600 cd/m² (Typ.) |
| nisbah kontras | 2000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 3.5/4.5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 88 pcsCCFLEmbedded (Inverter) |
| antara muka isyarat | LVDS (2 ch, 8-bit), 51 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | PID |
