| Nombor Bahagian | LSM315DP01-M01 |
| Jenama | SAMSUNG |
| Saiz | 32.0 |
| Permohonan | Desktop Monitor Gami |
| Resolusi | 2560×1440 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | eDP |
| jenama | SAMSUNG |
| saiz pepenjuru | 32.0 inch |
| format piksel | 2560(RGB)×1440 [Quad-HD] 93PPI |
| kawasan aktif | 697.344(H)×392.256(V) mm |
| kawasan bezel | - |
| kecerahan | 0 cd/m² |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| ketebalan plat | 0.40+0.40 mm |
| warna sokongan | 16.7M 70% NTSC |
| berat badan | 900g (Typ.) |
| kadar bingkai | 144Hz |
| perincian d-ic | COF Built-in 8 source chips |
| jenis antara muka | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| bekalan kuasa | 12.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | LSM315DP01-M01 |
| menaip | a-Si TFT-LCD , CELL |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 708.944(H)×405.731(V) ×1.11(D) mm |
| rawatan | Antiglare (Haze 25%) |
| nisbah kontras | 3000:1 (Typ.) (TM) |
| masa tindak balas | 22 (Typ.)(G to G) |
| mod operasi | PVA, Normally Black, Transmissive |
| penghantaran | 3.0% (Typ.)(with Polarizer) |
| sumber cahaya | No B/L |
| direka untuk | Desktop Monitor Gaming |
| panel sentuh | Without |
