| Nombor Bahagian | LSM270HP06-G01 |
| Jenama | SAMSUNG |
| Saiz | 27.0 |
| Permohonan | Desktop Monitor Gami |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LSM270HP06-G01 |
| saiz panel | 27.0" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 1920(RGB)×1080, FHD, 81PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 597.888(W)×336.312(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 608.288(W)×348.037(H) ×1.11(D) mm |
| permukaan | Antiglare |
| kecerahan | 0 cd/m² |
| nisbah kontras | 3000:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | SPVA, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 21 (Typ.)(G to G) |
| kedalaman kaca | - |
| ketransmisian | 4.25% (Typ.)(with Polarizer) |
| warna paparan | 16.7M 69% NTSC |
| jenis lampu | No B/L |
| kekerapan | 144Hz |
| skrin sentuh | Without |
| ic pemandu | COFBuilt-in 6 source chips |
| berat panel | 600g (Typ.) |
| permohonan | Desktop Monitor Gaming |
| antara muka isyarat | LVDS (4 ch, 8-bit) , 61 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
