| Nombor Bahagian | LSC480HN08-W |
| Jenama | SAMSUNG |
| Saiz | 48 |
| Permohonan | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | CELL, a-Si TFT-LCD |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antara muka | LVDS |
| pengilang | SAMSUNG |
| nama model | LSC480HN08-W |
| saiz skrin | 48 inch |
| jenis skrin | CELL, a-Si TFT-LCD |
| nombor piksel | 1920×1080(RGB) (FHD) 46PPI |
| susunan | RGB Horizontal Stripe |
| kawasan aktif (mm) | 1054.08 × 592.92 (H×V) |
| garis besar (mm) | 1068.08 × 608.92 × 1.4 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare (Haze 2.3%), Hard coating (2H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 5000 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 8 (Typ.)(G to G) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | SVA, Normally Black, Transmissive |
| ketebalan kaca | 0.50+0.50 mm |
| ketransmisian | 6.6% (Typ.)(with Polarizer) |
| kedalaman warna | 1.07B 68% NTSC |
| lampu latar | No B/L |
| jisim | 1.90Kgs (Typ.) |
| digunakan untuk | TV Sets |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| senarai ic pemandu | Built-in COF 3 source chips |
| jenis isyarat | LVDS (2 ch, 10-bit) , Connector 51 pins |
| bekalan voltan | 12.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
