| Nombor Bahagian | LSC320AN09-H |
| Jenama | SAMSUNG |
| Saiz | 32.0 |
| Permohonan | TV Sets |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| saiz panel | 32.0" |
| resolusi | 1366×768(RGB), WXGA, 49PPI |
| kawasan paparan | 697.685(W)×392.256(H) mm |
| saiz garis besar | 713(W)×410.5(H) ×1.3(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| kedalaman kaca | 0.50+0.50 mm |
| warna paparan | 16.7M 69% NTSC |
| kekerapan | 60Hz |
| ic pemandu | COF Built-in 1 source chips |
| berat panel | 800g (Typ.) |
| antara muka isyarat | LVDS (1 ch, 8-bit) , 30 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
| model panel | LSC320AN09-H |
| jenis panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Horizontal Stripe |
| pembukaan bezel | - |
| permukaan | Antiglare (Haze 2%), Hard coating (2H) |
| nisbah kontras | 4000:1 (Typ.) (TM) |
| mod paparan | SVA, Normally Black, Transmissive |
| masa tindak balas | 20 (Typ.)(G to G) |
| ketransmisian | 6.9% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| skrin sentuh | Without |
| permohonan | TV Sets |
