| Nombor Bahagian | LS019B3SX01 |
| Jenama | Sharp |
| Saiz | 1.9 |
| Permohonan | Handheld & PDA |
| Resolusi | 240×320 |
| Komposisi | LTPS TFT-LCD, LCM |
| Kecerahan | |
| CR | 2000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | Sharp |
| model panel | LS019B3SX01 |
| saiz panel | 1.9" |
| jenis panel | LTPS TFT-LCD, LCM |
| resolusi | 240(RGB)×320, QVGA, 210PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 29.172(W)×38.4285(H) mm |
| pembukaan bezel | 30.172(W)×40.025(H) mm |
| saiz garis besar | 33.57(W)×48.13(H) ×2.95(D) mm |
| permukaan | - |
| kecerahan | 650 cd/m² (Typ.) |
| nisbah kontras | 2000:1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥10) |
| mod paparan | New Mode2, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 20 (Typ.)(Tr/Td) |
| warna paparan | 16.7M 50% NTSC |
| jenis lampu | WLED , Without Driver |
| kekerapan | - |
| skrin sentuh | Without |
| berat panel | 10.5g (Typ.) |
| permohonan | Handheld & PDA |
| antara muka isyarat | MIPI (1 data lane) , 16 pins Connector |
| voltan masukan | 1.8/3.3V (Typ.)(VDDI/VCI) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
