| Nombor Bahagian | LQ800D3HA01 |
| Jenama | Sharp |
| Saiz | 80 |
| Permohonan | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | Sharp |
| model panel | LQ800D3HA01 |
| saiz panel | 80" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 1920(RGB)×1080, FHD, 27PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 1771.2(W)×996.3(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 1802.6(W)×1026.9(H) ×1.7(D) mm |
| permukaan | Antiglare (Haze 3%), Hard coating (2H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 5000:1 (Typ.) (TM) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10) |
| mod paparan | ASV, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 4 (Typ.)(G to G) |
| kedalaman kaca | - |
| ketransmisian | 6.51% (Typ.)(with Polarizer) |
| warna paparan | 1.07B 73% NTSC |
| jenis lampu | No B/L |
| kekerapan | 120Hz |
| skrin sentuh | Without |
| ic pemandu | COF Built-in 16 source + 10 gate chips |
| berat panel | 7.80g (Typ.) |
| permohonan | TV Sets |
| antara muka isyarat | LVDS (4 ch, 10-bit) , 92 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
