| Nombor Bahagian | LQ164M1LA4AB |
| Jenama | Sharp |
| Saiz | 16.4 |
| Permohonan | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | 2 |
| Antara muka | LVDS |
| jenama panel | Sharp |
| model panel | LQ164M1LA4AB |
| saiz panel | 16.4" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 134PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 362.88(W)×204.12(H) mm |
| pembukaan bezel | 367.2(W)×208.8(H) mm |
| saiz garis besar | 375(W)×222.1(H) ×7(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 315 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) (TM) |
| sudut pandangan | 70/70/50/60 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 6 o'clock |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| warna paparan | 262K 100% Adobe RGB |
| jenis lampu | 2 pcs CCFL , 12K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| gaya bentuk | Wedge (PCBA Bent, T≥5.2mm) |
| permohonan | Laptop |
| antara muka isyarat | LVDS (2 ch, 6-bit) , 30 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
