| Nombor Bahagian | LQ125M1JW31 |
| Jenama | Sharp |
| Saiz | 12.5 |
| Permohonan | Laptop Pad & Tablet |
| Resolusi | 1920×1080 |
| Komposisi | Oxide TFT-LCD , LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | Sharp |
| saiz panel | 12.5" |
| resolusi | 1920(RGB)×1080, FHD, 176PPI |
| kawasan paparan | 276.48(W)×155.52(H) mm |
| saiz garis besar | 282.08(W)×169.49(H) ×4.6(D) mm |
| kecerahan | 400 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 100% sRGB |
| kekerapan | 60Hz |
| gaya bentuk | Slim (PCBA Bent, T≤3.0mm) |
| antara muka isyarat | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 30 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
| model panel | LQ125M1JW31 (SHP144F) |
| jenis panel | Oxide TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating (3H) |
| nisbah kontras | 1500:1 (Typ.) (TM) |
| mod paparan | New Mode2, Normally Black, Transmissive |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 15K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Laptop Pad & Tablet |
| B125HAN01.0 | AUO | 12.5 | 1920×1080 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB3 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLB3 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| LQ125T1JW02 | SHARP | 12.5 | 2560×1440 |
| M125NWN1 R0 | IVO | 12.5 | 1366×768 |
| N125HCE-GN1 | Innolux | 12.5 | 1920×1080 |
