| Nombor Bahagian | LQ075V3DG01 |
| Jenama | SHARP |
| Saiz | 7.5 |
| Permohonan | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ075V3DG01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.5 inch |
| resolusi | 640(RGB)×480 , VGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 151.68×113.76 mm |
| garis besar | 179×139.5 mm |
| permukaan | Antiglare |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 5/21 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 33 pins |
| voltan masukan | 3.3V (Typ.)(VCC) |
| permohonan | IA |
