| Nombor Bahagian | LQ050A5AG03 |
| Jenama | Sharp |
| Saiz | 5.0 |
| Permohonan | Automotive Display |
| Resolusi | 320×234 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 60:1 |
| Warna | Full |
| Lampu latar | 1 |
| Antara muka | Analog |
| pengilang | Sharp |
| nama model | LQ050A5AG03 |
| saiz skrin | 5.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 320(RGB)×234 79PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 102.124 × 74.763 (H×V) |
| garis besar (mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antireflection |
| kecerahan | 320 cd/m² (Typ.) |
| nisbah kontras | 60 : 1 (Typ.) (TM) |
| sudut pandangan | 65/65/40/65 (Typ.)(CR≥5) |
| tindak balas | 30/50 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | Full color |
| lampu latar | 1 pcs CCFL , 10K hours , No Driver |
| jisim | 180g (Max.) |
| digunakan untuk | Automotive Display |
| kadar segar semula | - |
| skrin sentuh | Without |
| jenis isyarat | Analog RGB , Connector 22 pins |
| bekalan voltan | 8.0/-5.0V (Typ.)(VSH/VSL) |
| maks. penilaian | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
