| Nombor Bahagian | LPM035M407B |
| Jenama | JDI |
| Saiz | 3.5 |
| Permohonan | HMD VR AR |
| Resolusi | 1440×1600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama | JDI |
| model | LPM035M407B |
| saiz pepenjuru | 3.5 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1440(RGB)×1600 615PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 59.4(H)×66(V) mm |
| garis besar malap. | 62.2(H)×73.6(V) mm |
| kawasan bezel | - |
| rawatan | Hard coating |
| arah pandang | Symmetry |
| masa tindak balas | - |
| sudut pandangan | - |
| mod operasi | IPS, Normally Black, Transmissive |
| warna sokongan | 16.7M |
| sumber cahaya | WLED [5S2P] |
| berat badan | 17.0g (Typ.) |
| direka untuk | HMD VR AR |
| kadar bingkai | 90Hz |
| panel sentuh | Without |
| jenis antara muka | MIPI (4 data lanes) |
| bekalan kuasa | 1.8/5.7/-5.7V (Typ.)(VDDI/AVDD/AVEE) |
| persekitaran | Operating Temperature: -10 ~ 55 °C ; Storage Temperature: -20 ~ 70 °C |
