| Nombor Bahagian | LP156WHB-TPL1 |
| Jenama | LG Display |
| Saiz | 15.6 |
| Permohonan | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | LG Display |
| saiz panel | 15.6" |
| resolusi | 1366(RGB)×768, WXGA, 100PPI |
| kawasan paparan | 344.232(W)×193.536(H) mm |
| kecerahan | - |
| sudut pandangan | - |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K |
| kekerapan | 60Hz |
| gaya bentuk | - |
| antara muka isyarat | eDP (1 Lane) , 30 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | LP156WHB-TPL1 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| nisbah kontras | 500:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| jenis lampu | WLED , With LED Driver |
| skrin sentuh | Without |
| permohonan | Laptop |
| LP156WD1-TLD3 | LG Display | 15.6 | 1600×900 |
| LP156WF4-SPK1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TLA1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLBA | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLRA | LG Display | 15.6 | 1366×768 |
| LP156WH3-TLQ1 | LG Display | 15.6 | 1366×768 |
| LP156WH3-TLT2 | LG Display | 15.6 | 1366×768 |
| LP156WH4-TLN1 | LG Display | 15.6 | 1366×768 |
| LP156WH4-TLN2 | LG Display | 15.6 | 1366×768 |
| LP156WHU-TPE1 | LG Display | 15.6 | 1366×768 |
