| Nombor Bahagian | LP156WF9-SPN1 |
| Jenama | LG Display |
| Saiz | 15.6 |
| Permohonan | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | LG Display |
| saiz panel | 15.6" |
| resolusi | 1920(RGB)×1080, FHD, 141PPI |
| kawasan paparan | 344.16(W)×193.59(H) mm |
| saiz garis besar | 350.66(W)×205.8(H) ×4.4(D) mm |
| kecerahan | 300 cd/m² (Typ.) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 262K 99% sRGB |
| kekerapan | 60Hz |
| gaya bentuk | Slim (PCBA Bent, T≤3.0mm) |
| antara muka isyarat | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 30 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | LP156WF9-SPN1 (LGD05A8) |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Glare (Haze 0%) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | IPS, Normally Black, Transmissive |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 12K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Laptop |
| LP156WD1-TLB2 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLF4 | LG Display | 15.6 | 1920×1080 |
| LP156WF1-TPB1 | LG Display | 15.6 | 1920×1080 |
| LP156WF4-SLB1 | LG Display | 15.6 | 1920×1080 |
| LP156WH1-TLC2 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLD1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLG1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLR1 | LG Display | 15.6 | 1366×768 |
| LP156WH3-TPS2 | LG Display | 15.6 | 1366×768 |
| LP156WHB-TPD1 | LG Display | 15.6 | 1366×768 |
