Nombor Bahagian | LP129QE1-SPA1 |
Jenama | LG Display |
Saiz | 12.9 |
Permohonan | NBPC |
Resolusi | 2560×1700 |
Komposisi | LCM |
Kecerahan | 400 |
CR | 800:1 |
Warna | 16.7M |
Lampu latar | WLED |
Antara muka | eDP |
jenama panel | LG Display |
model panel | LP129QE1-SPA1 |
jenis panel | a-Si TFT-LCD , LCM |
saiz panel | 12.9 inch |
resolusi | 2560(RGB)×1700 |
mod paparan | AH-IPS, Normally Black, Transmissive |
kawasan aktif | 271.9×180.5 mm |
garis besar | 283.3×195 mm |
gaya bentuk | Slim (PCBA Flat, Depth ≤3.2mm) |
permukaan | Hard coating |
kecerahan | 400 cd/m² (Typ.) |
nisbah kontras | 800:1 (Typ.) |
warna paparan | 16.7M (8-bit), CIE193165% |
masa tindak balas | 20 (Typ.)(Tr+Td) |
sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
kekerapan | 60Hz |
jenis lampu | WLEDWithout Driver |
antara muka isyarat | eDP (4 Lanes), 40 pins |
voltan masukan | 3.3V (Typ.) |
permohonan | NBPC |
