| Nombor Bahagian | LM340WW1-SSA1 |
| Jenama | LG Display |
| Saiz | 34 |
| Permohonan | DMPC |
| Resolusi | 2560×1080 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | LG Display |
| model panel | LM340WW1-SSA1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 34 inch |
| resolusi | 2560(RGB)×1080 , CSHD |
| mod paparan | AH-IPS, Normally Black, Transmissive |
| kawasan aktif | 799.8×334.8 mm |
| garis besar | 820.8×361×19.8 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), sRGB |
| masa tindak balas | 14 (Typ.)(Tr+Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | LVDS (4 ch, 8-bit), 92 pins |
| voltan masukan | 10.0V (Typ.) |
| permohonan | DMPC |
