LG Display LM240WU8-SLA3 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com

LM240WU8-SLA3


Jenama
LG Display
Saiz
24.0
Permohonan
DMPC
Resolusi
1920×1200
Komposisi
LCM
Kecerahan
350
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
54
Spesifikasi

Nombor Bahagian LM240WU8-SLA3
JenamaLG Display
Saiz24.0
PermohonanDMPC
Resolusi1920×1200
KomposisiLCM
Kecerahan350
CR1000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelLG Display
model panelLM240WU8-SLA3
jenis panel a-Si TFT-LCD , LCM
saiz panel24.0 inch
resolusi1920(RGB)×1200 , WUXGA
mod paparane-IPS, Normally Black, Transmissive
kawasan aktif518.4×324 mm
garis besar546.4×352×15 mm
permukaanAntiglare, Hard coating (3H)
kecerahan350 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M (6-bit + Hi-FRC), CIE193172%
masa tindak balas14 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu4 stringsWLEDWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan12.0V (Typ.)
permohonanDMPC
Model Keluarga
LM240WU2-SLB1 LG Display 24.0 1920×1200
LM240WU4-SLB1 LG Display 24.0 1920×1200
LM240WU7-SLA1 LG Display 24.0 1920×1200
LM240WU7-SLB1 LG Display 24.0 1920×1200
LM240WU7-SLB3 LG Display 24.0 1920×1200
LM240WU8-SLA3 LG Display 24.0 1920×1200
LM240WU8-SLD1 LG Display 24.0 1920×1200
LM240WU8-SLD2 LG Display 24.0 1920×1200
LM240WU8-SLD4 LG Display 24.0 1920×1200
LM240WU8-SLE1 LG Display 24.0 1920×1200
