LM190E02-A4

LM190E02-A4
LM190E02-A4 thumb
Jenama
LG Display
Saiz
19.0
Permohonan
DMPC
Resolusi
1280×1024
Komposisi
LCM
Kecerahan
250
CR
500:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
14557
Spesifikasi

Nombor Bahagian LM190E02-A4
JenamaLG Display
Saiz19.0
PermohonanDMPC
Resolusi1280×1024
KomposisiLCM
Kecerahan250
CR500:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelLG.Philips LCD
model panelLM190E02-A4
jenis panel a-Si TFT-LCD , LCM
saiz panel19.0 inch
resolusi1280(RGB)×1024 , SXGA
mod paparanS-IPS, Normally Black, Transmissive
kawasan aktif376.32×301.056 mm
garis besar404.2×330×20.5 mm
permukaanAntiglare, Hard coating (3H)
kecerahan250 cd/m² (Typ.)
nisbah kontras500:1 (Typ.)
warna paparan16.7M (8-bit)
masa tindak balas12/13 (Typ.)(Tr/Td)
sudut pandangan88/88/88/88 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu4 pcsCCFLWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan12.0V (Typ.)
permohonanDMPC
