LG Display LM170E03-TLH1 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LM170E03-TLH1

LM170E03-TLH1
LM170E03-TLH1
LM170E03-TLH1 thumb LM170E03-TLH1 thumb
Jenama
LG Display
Saiz
17.0
Permohonan
DMPC
Resolusi
1280×1024
Komposisi
LCM
Kecerahan
250
CR
800:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
1410
Spesifikasi

Nombor Bahagian LM170E03-TLH1
JenamaLG Display
Saiz17.0
PermohonanDMPC
Resolusi1280×1024
KomposisiLCM
Kecerahan250
CR800:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelLG Display
model panelLM170E03-TLH1 3 Compatible model
jenis panel a-Si TFT-LCD , LCM
saiz panel17.0 inch
resolusi1280(RGB)×1024 , SXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif337.92×270.336 mm
garis besar358.5×296.5×16.5 mm
permukaanAntiglare, Hard coating (3H)
kecerahan250 cd/m² (Typ.)
nisbah kontras800:1 (Typ.)
warna paparan16.7M (6-bit + Hi-FRC)
masa tindak balas1.2/3.8 (Typ.)(Tr/Td)
sudut pandangan85/85/75/85 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu2 pcsCCFLWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
Model Keluarga
LM170E01-A4 LG Display 17.0 1280×1024
LM170E01-A6 LG Display 17.0 1280×1024
LM170E01-TLB3 LG Display 17.0 1280×1024
LM170E03-TLB1 LG Display 17.0 1280×1024
LM170E03-TLG1 LG Display 17.0 1280×1024
LM170E03-TLJ1 LG Display 17.0 1280×1024
LM170E03-TLJ2 LG Display 17.0 1280×1024
LM170E03-TLJ5 LG Display 17.0 1280×1024
LM170E03-TLL1 LG Display 17.0 1280×1024
LM170E03-TLL2 LG Display 17.0 1280×1024
