| Nombor Bahagian | LM116LF3L01 |
| Jenama | PANDA |
| Saiz | 11.6 |
| Permohonan | Pad & Tablet |
| Resolusi | 1920×1080 |
| Komposisi | Oxide TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama | PANDA |
| saiz pepenjuru | 11.6 inch |
| format piksel | 1920(RGB)×1080 [FHD] 190PPI |
| kawasan aktif | 256.32(H)×144.18(V) mm |
| kawasan bezel | - |
| kecerahan | 300 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 100% sRGB |
| berat badan | 215g (Max.) |
| kadar bingkai | 60Hz |
| jenis antara muka | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| model | LM116LF3L01 (NCP000A) |
| menaip | Oxide TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 268(H)×168(V) ×3(D) mm |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| mod operasi | FFS, Normally Black, Transmissive |
| sumber cahaya | WLED , 15K hours , With LED Driver |
| direka untuk | Pad & Tablet |
| panel sentuh | Without |
| B116AW02 V0 | AUO | 11.6 | 1024×600 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XTB01.0 | AUO | 11.6 | 1366×768 |
| B116XW02 V1 | AUO | 11.6 | 1366×768 |
| B116XW05 V004 | AUO | 11.6 | 1366×768 |
| HN116WX1-203 | BOE | 11.6 | 1366×768 |
| LP116WH4-SLA1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R0 | IVO | 11.6 | 1366×768 |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
| N116BGE-L41 | Innolux | 11.6 | 1366×768 |
