| Nombor Bahagian | LD550DUN-TKH1 |
| Jenama | LG Display |
| Saiz | 55 |
| Permohonan | Video Wall |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1300:1 |
| Warna | 1.06B |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | LG Display |
| model panel | LD550DUN-TKH1 |
| saiz panel | 55" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 40PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 1209.6(W)×680.4(H) mm |
| pembukaan bezel | 1209.9(W)×680.7(H) mm |
| saiz garis besar | 1213.4(W)×684.2(H) ×57.2(D) mm |
| permukaan | Antiglare (Haze 3%), Hard coating (2H), Antireflection |
| kecerahan | 1500 cd/m² (Typ.) |
| nisbah kontras | 1300:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10) |
| mod paparan | S-IPS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 8 (Typ.)(G to G) |
| warna paparan | 1.06B 72% NTSC |
| jenis lampu | WLED , 60K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| jahitan dinding video | 3.8 mm (active to active seam) |
| permohonan | Video Wall |
| antara muka isyarat | LVDS (2 ch, 10-bit) , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
