| Nombor Bahagian | LC550EQF-YJF1 |
| Jenama | LG Display |
| Saiz | 55 |
| Permohonan | TV Sets |
| Resolusi | 3840×2160 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1400:1 |
| Warna | 16.7M/1.06B |
| Lampu latar | WLED |
| Antara muka | V-by-One |
| jenama panel | LG Display |
| model panel | LC550EQF-YJF1 |
| saiz panel | 55" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 3840(RGB)×2160, UHD, 80PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 1209.6(W)×680.4(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 1232.2(W)×708.6(H) ×50.1(D) mm |
| permukaan | Antiglare (Haze 3%), Hard coating (2H) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 1400:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10) |
| mod paparan | IPS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) |
| warna paparan | 16.7M/1.06B 87% NTSC |
| jenis lampu | WLED , 30K hours , Without Driver |
| kekerapan | 120Hz |
| skrin sentuh | Without |
| berat panel | 12.5/13.2Kgs (Typ.) |
| permohonan | TV Sets |
| antara muka isyarat | V-by-One 16 lane , 97 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LC550EQD-FGF4 | LG Display | 55 | 3840×2160 |
| LC550EQE-PGF1 | LG Display | 55 | 3840×2160 |
| LC550EQE-PHF1 | LG Display | 55 | 3840×2160 |
| LC550EUE-SEM1 | LG Display | 55 | 1920×1080 |
| LC550EUF-FEP1 | LG Display | 55 | 1920×1080 |
| LC550EUF-FGF1 | LG Display | 55 | 1920×1080 |
| LC550EUG-KEF1 | LG Display | 55 | 1920×1080 |
| LC550EUH-RDA2 | LG Display | 55 | 1920×1080 |
| LC550EUN-FFM1 | LG Display | 55 | 1920×1080 |
| LC550EUN-SFF1 | LG Display | 55 | 1920×1080 |
