| Nombor Bahagian | LC470EUG-PEF2 |
| Jenama | LG Display |
| Saiz | 47 |
| Permohonan | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1400:1 |
| Warna | 1.06B |
| Lampu latar | WLED |
| Antara muka | EPI |
| jenama panel | LG Display |
| model panel | LC470EUG-PEF2 |
| saiz panel | 47" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 46PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 1039.68(W)×584.82(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 1059.5(W)×616.2(H) mm |
| permukaan | Antiglare (Haze 1%), Hard coating (2H) |
| kecerahan | 360 cd/m² (Typ.) |
| nisbah kontras | 1400:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10) |
| mod paparan | S-IPS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 8/10 (Typ.)(Tr/Td) |
| warna paparan | 1.06B 68% NTSC |
| jenis lampu | WLED , 50K hours , Without Driver |
| kekerapan | 120Hz |
| skrin sentuh | Without |
| berat panel | 10.5/11.0Kgs (Typ./Max.) |
| permohonan | TV Sets |
| antara muka isyarat | EPI , 100 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
