| Nombor Bahagian | LA123WF4-SR05 |
| Jenama | LG Display |
| Saiz | 12.3 |
| Permohonan | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 8S6P |
| Antara muka | RSDS |
| jenama panel | LG Display |
| model panel | LA123WF4-SR05 |
| saiz panel | 12.3" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×720, 167PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 292.032(W)×109.512(H) mm |
| pembukaan bezel | 296.03(W)×113.5(H) mm |
| saiz garis besar | 310(W)×128(H) ×10.75(D) mm |
| permukaan | Hard coating |
| kecerahan | 420 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Min.) (TM) |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10) |
| mod paparan | IPS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| warna paparan | 16.7M 77% NTSC |
| jenis lampu | 8S6P WLED , 10K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 395/405g (Typ./Max.) |
| permohonan | Automotive Display |
| antara muka isyarat | RSDS (2 Channel) , 110 pins FPC |
| voltan masukan | 3.3/13.0V (Typ.)(VCC/VDD) |
| persekitaran | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
