| Nombor Bahagian | LA123WF4-SL02 |
| Jenama | LG Display |
| Saiz | 12.3 |
| Permohonan | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | 11S4P |
| Antara muka | |
| pengilang | LG Display |
| nama model | LA123WF4-SL02 |
| saiz skrin | 12.3 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×720 167PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 292.032 × 109.512 (H×V) |
| garis besar (mm) | 310.4 × 128.9 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Hard coating |
| kecerahan | 650 cd/m² (Typ.) |
| nisbah kontras | 900 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10) |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 86% NTSC |
| lampu latar | 11S4P WLED , 10K hours , No Driver |
| jisim | 481/496g (Typ./Max.) |
| digunakan untuk | Automotive Display |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
