| Nombor Bahagian | KHS072VG1MB-G40 |
| Jenama | Kyocera |
| Saiz | 7.2 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | CSTN-LCD, LCM |
| Kecerahan | |
| CR | 5:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antara muka | |
| jenama | Kyocera |
| model | KHS072VG1MB-G40 |
| saiz pepenjuru | 7.2 inch |
| menaip | CSTN-LCD, LCM |
| format piksel | 640(RGB)×480 [VGA] 111PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 145.9(H)×109.42(V) mm |
| garis besar malap. | 179.3(H)×130.5(V) ×6.5(D) mm |
| kawasan bezel | 147.9(H)×111.42(V) mm |
| rawatan | - |
| kecerahan | - |
| nisbah kontras | 5:1 (Typ.) (RF) |
| arah pandang | - |
| masa tindak balas | 200/150 (Typ.)(Tr/Td) |
| sudut pandangan | 50/50/40/30 (Typ.)(CR≥2) |
| mod operasi | STN, Normally Black, Transflective |
| warna sokongan | Color |
| sumber cahaya | CCFL [1 pcs] , 40K hours , Optional |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 75Hz |
| panel sentuh | Without |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
