| Nombor Bahagian | JR645R3HA3L |
| Jenama | SDP |
| Saiz | 65 |
| Permohonan | TV Sets |
| Resolusi | 3840×2160 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antara muka | V-by-One |
| jenama panel | SDP |
| model panel | JR645R3HA3L |
| saiz panel | 65" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 3840(RGB)×2160, UHD, 68PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 1428.48(W)×803.52(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 1440.28(W)×815.92(H) ×1.33(D) mm |
| permukaan | Antiglare (Haze 5%), Hard coating (2H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 4000:1 (Typ.) (TM) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10) |
| mod paparan | UV2A, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 8 (Typ.)(G to G) |
| kedalaman kaca | 0.50+0.50 mm |
| ketransmisian | 5.1% (Typ.)(with Polarizer) |
| warna paparan | 1.07B 71% NTSC |
| jenis lampu | No B/L |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| ic pemandu | COF Built-in 12 source chips |
| berat panel | 3.45±0.17Kgs |
| permohonan | TV Sets |
| antara muka isyarat | V-by-One 8 lane , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
