| Nombor Bahagian | JJ103IA-12A |
| Jenama | Innolux |
| Saiz | 10.3 |
| Permohonan | Outdoor High Brightn |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1300:1 |
| Warna | 16.7M |
| Lampu latar | 4 |
| Antara muka | LVDS |
| jenama panel | Innolux |
| saiz panel | 10.3" |
| resolusi | 1920(RGB)×720, 200PPI |
| kawasan paparan | 243.648(W)×91.368(H) mm |
| saiz garis besar | 255.24(W)×106.68(H) mm |
| kecerahan | 800 cd/m² (Typ.) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 71% NTSC |
| kekerapan | 60Hz |
| berat panel | 380g (Max.) |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 50 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| model panel | JJ103IA-12A |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 246.65(W)×94.37(H) mm |
| permukaan | Antiglare |
| nisbah kontras | 1300:1 (Typ.) (TM) |
| mod paparan | IPS, Normally Black, Transmissive |
| masa tindak balas | 27 (Typ.)(Tr+Td) |
| jenis lampu | 4 strings WLED , 10K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Outdoor High Brightness Automotive Display |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
