| Nombor Bahagian | HV480FH2-600 |
| Jenama | BOE |
| Saiz | 48 |
| Permohonan | LCTV |
| Resolusi | 1920×1080 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | HV480FH2-600 |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 48 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | ADS, Normally Black, Transmissive |
| kawasan aktif | 1054.08×592.92 mm |
| garis besar | 1064.1×605.4 mm |
| permukaan | Antiglare (Haze 1%) |
| ketransmisian | 5.8% (Typ.)(with Polarizer) |
| nisbah kontras | 1200:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 8 (Typ.)(G to G) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| antara muka isyarat | LVDS (2 ch, 10-bit), 51 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
| HV320WX2-206 | BOE | 31.5 | 1366×768 |
| LC430EUE-FHM2 | LG Display | 43 | 1920×1080 |
| LK260T3LA17 | SHARP | 26.0 | 1366×768 |
| LM320TU4A | PANDA | 31.5 | 1366×768 |
| ST5461B03-1 | CSOT | 55 | 1920×1080 |
| T315HW02 V5 | AUO | 31.5 | 1920×1080 |
| T645HW05 V0 | AUO | 65 | 1920×1080 |
| V216BG1-LE1 | Innolux | 21.6 | 1366×768 |
| V236H1-LE4 | Innolux | 23.6 | 1920×1080 |
| V460H1-LS2 | Innolux | 46 | 1920×1080 |
