| Nombor Bahagian | HSD156JUW2-A13 |
| Jenama | HannStar |
| Saiz | 15.6 |
| Permohonan | Outdoor High Brightn |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 4 |
| Antara muka | LVDS |
| jenama panel | HannStar |
| saiz panel | 15.6" |
| resolusi | 1920(RGB)×1080, FHD, 141PPI |
| kawasan paparan | 344.16(W)×193.59(H) mm |
| saiz garis besar | 363.7(W)×215.7(H) mm |
| kecerahan | 850 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 70% |
| kekerapan | 60Hz |
| berat panel | TBD |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 50 pins Connector |
| voltan masukan | 5.0V (Typ.) |
| persekitaran | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model panel | HSD156JUW2-A13 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| mod paparan | IPS Pro, Normally Black, Transmissive |
| masa tindak balas | 15/15 (Max.)(Tr+Td) |
| jenis lampu | 4 strings WLED , 30K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Outdoor High Brightness Automotive Display |
