| Nombor Bahagian | HSD080JHW3-A11 |
| Jenama | HannStar |
| Saiz | 8.0 |
| Permohonan | Outdoor High Brightn |
| Resolusi | 1280×720 |
| Komposisi | , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| pengilang | HannStar |
| nama model | HSD080JHW3-A11 |
| saiz skrin | 8.0 inch |
| jenis skrin | , a-Si TFT-LCD |
| nombor piksel | 1280(RGB)×720 (WXGA) 184PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 176.64 × 99.36 (H×V) |
| garis besar (mm) | - |
| kawasan bezel (mm) | - |
| rawatan | Antireflection |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 17/18 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | IPS Pro, Normally Black, Transmissive |
| kedalaman warna | 262K/16.7M |
| lampu latar | WLED , No Driver |
| jisim | - |
| digunakan untuk | Outdoor High Brightness Automotive Display |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
