| Nombor Bahagian | HN116WXA-200 |
| Jenama | BOE |
| Saiz | 11.6 |
| Permohonan | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, Assemb |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama | BOE |
| model | HN116WXA-200 (BOE064A) |
| saiz pepenjuru | 11.6 inch |
| menaip | a-Si TFT-LCD, Assembly |
| format piksel | 1366(RGB)×768 [WXGA] 135PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 256.125(H)×144(V) mm |
| garis besar malap. | 293.3(H)×183(V) ×4(D) mm |
| kawasan bezel | - |
| rawatan | Hard coating (7H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 28 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | ADS, Normally Black, Transmissive |
| warna sokongan | 262K 60% NTSC |
| sumber cahaya | WLED [9S4P] , 15K hours , With LED Driver |
| gaya bentuk | - |
| direka untuk | Laptop |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
