| Nombor Bahagian | GV185FHM-N10-3M30 |
| Jenama | BOE |
| Saiz | 18.5 |
| Permohonan | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | BOE |
| model | GV185FHM-N10-3M30 |
| saiz pepenjuru | 18.5 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×1080 [FHD] 119PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 408.96(H)×230.04(V) mm |
| garis besar malap. | 430.4(H)×254.6(V) ×12.5(D) mm |
| kawasan bezel | 410.96(H)×232.04(V) mm |
| rawatan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | ADS, Normally Black, Transmissive |
| warna sokongan | 16.7M 70% NTSC |
| sumber cahaya | WLED [11S4P] , With LED Driver |
| berat badan | 1.80Kgs (Typ.) |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (2 ch, 8-bit) , 30 pins Connector |
| bekalan kuasa | 5.0V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
| G185BGE-L01 | Innolux | 18.5 | 1366×768 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| LM185TT4A | PANDA | 18.5 | 1366×768 |
| LM185WH1-TLD3 | LG Display | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| MT185WHM-N20 | BOE | 18.5 | 1366×768 |
| V185B1-LE1 | Innolux | 18.5 | 1366×768 |
